Screw pump, eccentric SP 10 B2, two-speed, Kiesel

Eccentric screw pumps belong to the group of rotary displacement pumps with the ability to self-suck the pumped medium.

The pump rotor rotates, and as a result, the substances filling the chambers are transferred in a screw manner from the suction side to the discharge side. The rotors in KIESEL screw pumps have a relatively large eccentricity in relation to the stroke. Thanks to this, it is possible to transfer large solids without fear of damaging the pump. Screw pumps perfectly suck in and pump liquids of various viscosities and consistency. The pumped liquids are not subjected to centrifugal or pulsating forces, thanks to which screw pumps successfully pump very delicate even the most sensitive media.

APPLICATION:

The presented pump is perfect for pumping (transporting): fruit pulps, mashes, beer wort, grape and fruit pulps, pomace, but also for wine, beer, fresh juices, fruit musts, crushed fruit, fruit and vegetable preserves. The advantages of the pump include its mobility.

TECHNICAL DATA:

• Suction side thread DIN DN 80
• Pressure side thread DIN DN 80
• Housing, stainless steel AISI 304, 1.4301
• Max. temperature 100°C
• Max. suction height 5 m
• Max. pressure 6 bar
• Max. capacity 12,500 or 25,000 l/h (two speeds)
• Direction of rotation left - right
• Power: 4.7/5.9 kW / speed: 448/888 rpm
• Voltage 400 V / Frequency: 50 Hz
• Protection class: IP55

Optional additional equipment:

• Dry-running protection sensor
• Electronic flow meter
• Pressure sensor
• Pump remote control
