DESCRIPTION
Washing system of stainless steel for fruits and vegetables with attached pivoting centrifugal mill. The washing system consists of sorting grid, washing vessel, chain conveyor and add-on pivoting centrifugal mill RM4. The conveyor speed can be adjusted by using the integrated frequency converter. The Elevator is suitable for different foods e.g. fruits, berries or vegetables. Due to the movability, there is a use with our without the Centrifugal mill possible without any modification work.
The SA300 perfectly fits in performance into the voran® product range. Despite lower hourly output, the SA300 convinces with the same characteristics and advantages as the SA400. For getting best crushing results of vegetables the machine can be equipped optionally with a suitable tool.
| Technical data |
| Scope of supply |
cutting screen 7 mm, 9 mm and 12 mm |
| Height mash outlet |
1 570 mm |
| Connection for washing vessel |
1 ½ “ |
| Connection for cleaning |
½ “ |
| Material |
1.4301 / AISI 304 |
| Weight |
350 kg |
| Discharge height |
850 mm |
| Height |
2 590 mm |
| Width |
940 mm |
| Length |
3 540 mm |
| Electrical protection |
16 A |
| Connected load |
400V 50Hz (3 phases) |
| Motor rating |
Elevator 0,55 (0,75) / Mill 4 (5,4) kW (PS) |
| Nominal rating kg/h |
1 000 - 3 000 kg/h |
Processable materials
Apples, Pears, Vegetables, Carrots, Cherries, Manioc, Tomatoes, Quince, Beetroot.
This represents just an example, based on different materials and a selection of fruit processed in practice.
|
