Bag-in-Box filling machine
Manual Bag in Box filling system with feed line vessel for hot filling of fruit and vegetable juice in 3, 5, 10 and 20 l standard
see full description
Gross price: 10 381 €
Net price: 8 440 €
DESCRIPTION
Manual Bag in Box filling system with feed line vessel for hot filling of fruit and vegetable juice in 3, 5, 10 and 20 l standard Bags.
| Technical data | |
|---|---|
| Scope of supply | Reinigungsadapter |
| Juice vessel | 54 l |
| Connection for juice inlet | ø 19 mm |
| Compressed air connection | 6 bar |
| Filling accuracy | ± 0,5 % |
| Material | 1.4301 / AISI 304 |
| Weight | 85 kg |
| Height | 1 075 mm |
| Width | 790 mm |
| Length | 1 280 mm |
| Electrical protection | 16 A |
| Connected load | 230V 50Hz (einphasig) |
| Nominal rating l/h | 750 (bei 10l Bags) l/h |
